8MP HD H.264/H.265 Infrared Network IP Corner Camera Support Audio, P2P, 12VDC/PoE
This unit is 802.3af POE. This unit can also be used with a 12VDC2A power source as well.
(Power Adapter NOT INCLUDED, Sold Separately)
Wide Angle View Corner Mount HD IP Camera IPCX-MC128MPA is great for any indoor application. Constructed with a durable aluminum housing, this tri-angle camera special design allows it to be placed on any corner of the inside of the building. With built-in 1pc of 3W Array LED it provides a 8MP HD picture quality during Day and Night, and picks up the clear sounds with built in hi-sensitive microphone, 2.8mm lens let it offer you wide angle view of your space. The IPCX-MC128MPA is perfect for the elevator.
Main Features :
- Supporting human detection and support to customize other intelligent functions
- 8.0MP HD Low illumination resolution, clear and fine images;
- Support 2D/3D noise reduction, digital wide dynamic;
- Advanced H.265+ (Compatible with H.265/H.264) video compression, Super low rate, high definition quality of image;
- Professional anti-lightning, conform to GB/T17626.5 and IEC61000-4-5。
- Support various mobile monitoring(iPhone, Android); APP(XMPEYE Pro or ICSee)
- Provide web, CMS, center platform management software MYEYE, provide SDK development
- Support cloud technology, easy to achieve network penetration, fro in-line and alarm information pushed
Specifications:
| Camera |
| Sensor | Embedded RTOS, dual-core 32bit DSP, pure hard compression ,watch dog |
| Min illumination | color 0.01Lux@F1.2,black/white 0.001Lux@F1.2 |
| Shutter | 1/50(1/60)s to 1/10,000s |
| Lens | 2.8mm Lens |
| Day and night | Auto IR-Cut |
| Video Compression | H.265 +(Compatible with H.265/H.264), |
| Video bit rate | support dual stream,AVI;0.1M~8Mpbs variable;1~25f/s variable |
| Resolution | Main stream:8M 38402160@15fps,5MP 28801616@25fps,4MP 25601440@25fps,2MP19201080@25 |
| Sub Stream :800*488@25fps |
| Audio compression | G.711,support bidirectional talk, audio& video synchronization |
| Intelligence analysis | Supporting human detection, and support to customize other intelligent functions |
| Storage | Via PC/Mobile Phone/NVR With HDD |
| Protocol | 1 * RJ45, 10/100M; Support TCP/IP HTTPS/RTSP/FTP/PPPOE/DHCP/DNS/DDNS/NTP/UPnP |
| Noise Reduction | |
| Supports 2D/3D |
| Working condition | -10~60 degree. humidity less than 90%(non-condensing) |
| Power | 12VDC; PoE(802.3af) (power supply not included) |
| Material | Metal ,Indoor Use |
Package List:
- 1x8MP Corner Camera
- 1xScrews
