HD 1080P H.264 Infrared Network IP Corner Camera Support Audio, Onvif, P2P,
12VDC/PoE
Wide Angle View Corner Mount HD IP Camera IPCX-MC28121080 is great for any
indoor application. Constructed with a durable aluminum housing, this tri-angle
camera special design allows it to be placed on any corner of the inside of the
building. With built-in 1pc of 3W Array LED it provides a 1080p HD picture
quality during Day and Night, and picks up the clear sounds with built in
hi-sensitive microphone, 3.6mm lens let it offer you wide angle view of your
space. The IPCX-MC28121080 is perfect for the elevator.
Feature:
- 1/2.8" progressive scan CMOS image sensor
- H.264 encoding, 1080P(1920*1080),2.0MegaPixel
- Built-in Web Server, Remote Setup
- Lens: 3.6mm Lens
- Day& Night(ICR) auto-switch, 1PC Array Led
- Image snapshot, Title OSD, DDNS
- Support up to 10 users online simultaneously
- Free 64CH CMS Software
- Support P2P function, easy remote monitoring
- Onvif 2.0 version Compliant
- Image Controls: Brightness, saturation, contrast, hue adjustable
- Smart Phone Support: iPhone, iPad, Android
- Support built-in Power over Ethernet (PoE), this camera is build-in PoE
camera. but if you want this camera can powered by Ethernet. you also need a
PoE splitter or PoE switch.
Functions:
-
Title OSD: Supports channel name, date, and video stream information overlay;
- Privacy Mask: 4 configurable regions
- Image Orientation: image flip and mirror
-
Auto Exposure Control (AEC); Auto White Balance (AWB); Auto Band Filter (ABF)
- Auto Black Level Calibration (ABLC)
-
Network protocol: TCP/IP UDP RTP RTSP RTCP HTTP DNS DDNS DHCP FTP NTP PPPOE SMTP UPNP
- ONVIF protocols: Support 2.0 Version
- Remote View: IE 6.0 or later, Firefox, chrome
- Network Interface: 10/100M BASE-TX,RJ-45 connector
Video encoding:
Video Compression: H.264 main profile, support
dual stream, AVI format; support 0.1M~6Mpbs bit rate adjustable; support 1~30fps
adjust
Main Stream: 1920*1080P
Video Bitrates: 32Kbps~4Mbps,Supports
CBR/VBR
General Specifications:
- Operating Temperature: -20 °C ~ 50 °C (-4 °F ~ 122 °F)
- Operating Humidity: 0% -85% RH
- Power: DC12V
- Power Consumption: 9W (MAX)
Package Included:
- 1x 2.0 MP 1080P IP Camera
- 1x CD Manual
- Notes: This model is suitable DC12, 1.5A power adapter, but not included
Software Download:

DSC SERIES IP Camera
