PoE Splitter 48V PoE to 12V 2A DC for Non-PoE IP Camera

(image for) PoE Splitter 48V PoE to 12V 2A DC for Non-PoE IP Camera
PoE Splitter 48V PoE to 12V 2A DC for Non-PoE IP Camera
  • Model: PS5712T
  • Shipping Weight: 0.25 lbs
  • 20 Units in Stock

 Ask a Question
✓Warranty
◉Free Lifetime Tech Support
▣Fast U.S. Shipping
🔒Secure Checkout


$18.95

In Stock Ready for order
Add to Cart:
BEFORE YOU ORDER

Compatibility & Installation

Confirm the key installation details before purchasing to help avoid compatibility issues and returns.

⚡
Power / PoE Verify voltage, amperage, PoE standard, and power-supply requirements.
▣
Recorder / Network Confirm recorder type, supported resolution, protocol, and network requirements.
↔
Connections Check connector type, cabling, adapters, and required accessories.
⌂
Mounting / Environment Confirm mounting location, indoor/outdoor rating, dimensions, and installation space.
Not sure if this product will work with your system? Send us your existing model number or installation details before ordering.
Ask Compatibility Question

Product Overview

POE Splitter Cable Adapter IEEE802.3at 12VDC 2A For IP Cameras

Main Features:

  • RJ45 female INPUT Port:
  • Support the IEEE 802.3at the Power over Ethernet PoE Switch
  • Support 48V Unsolicited Power Over Ethernet PoE Switch
  • Support 48V Unsolicited Power Over Ethernet PoE Adapter

Specification:

  • Compliant with IEEE802.3at 30W
  • Power Input: DC44~57V
  • Power Output: DC12V, max 2A
  • Splits the 48V DC power over RJ-45 Ethernet cable into different DC output
  • Data & Power INPUT Port: from RJ45 female
  • Data Output Port: RJ45 Male
  • Power Output Port: 5.5x2.1mm DC Power Plug
  • Data Transfer Rate: 10/100Mbps
  • Devices will be detected before poe input
  • Power Pin: support both 1/2(+),3/6(-) or 4/5(+),7/8(-)
  • Body size: 80 x 26x 26 mm
  • DC cable length：210mm
  • RJ45 Modular Plug cable length：210mm

Package Included:

  • PoE Splitter x1
