Supported IP Camera Protocols
- Axis
- Dahua
- Digital Watchdog
- Hanwha
- ONVIF
- Vivotek
Camera compatibility and available features vary by camera model, recorder firmware and the selected protocol.
Premium NDAA HNRA20N-64 64-Channel Network Video Recorder
Product Overview
The Premium NDAA HNRA20N-64 is a professional 64-channel Network Video Recorder designed for large commercial, enterprise, campus, municipal, and multi-site surveillance systems.
Supporting recording resolutions up to 32MP and up to 400 Mbps incoming and outgoing bandwidth with recorder-side AI disabled, the IPC-HNRA20N-64 is designed to manage large numbers of high-resolution IP cameras while maintaining reliable recording and playback performance.
The recorder includes 8 internal SATA drive bays supporting up to 16TB per drive for a maximum supported storage capacity of up to 128TB. Dual HDMI and dual VGA display outputs provide flexible multi-monitor viewing for professional security control rooms.
Built-in intelligent analytics include recorder-side motion detection, perimeter detection, face capture and recognition, while compatible cameras can provide additional smart analytics including license plate recognition and intelligent search functions.
Key Features
- 64-Channel IP Video Recording: Supports up to 64 compatible IP cameras.
- Up to 32MP Recording: Supports ultra-high-resolution IP cameras for detailed surveillance applications.
- High Bandwidth Capacity: Up to 400 Mbps incoming and outgoing bandwidth with recorder-side AI disabled.
- 8-Bay HDD Storage: Eight internal SATA interfaces support surveillance hard drives up to 16TB each.
- Up to 128TB Storage: Large internal storage capacity for extended recording retention.
- Smart H.265+ Compression: Supports H.265+, H.265, H.264+, H.264 and MJPEG decoding formats.
- Dual HDMI Outputs: Supports independent HDMI display outputs up to 4K resolution.
- Dual VGA Outputs: Provides additional local display flexibility for monitoring stations.
- Independent Multi-Display Support: HDMI and VGA outputs can be configured for flexible control-room layouts.
- Intelligent Motion Detection: Supports camera-driven and NVR-driven intelligent motion detection.
- Video Content Analytics: Supports compatible perimeter detection and intelligent event processing.
- Face Recognition: Supports recorder-side face capture and recognition with compatible face databases.
- License Plate Recognition: Supports up to 8 compatible LPR camera channels with plate database management.
- Smart Search: Supports intelligent search functions with compatible cameras.
- ONVIF Compatible: Supports compatible ONVIF and RTSP network cameras.
- NeoViewer Mobile App: Remote viewing and compatible system management from iPhone and Android devices.
- TAA Compliant: Suitable for projects requiring TAA-compliant surveillance equipment.
- NDAA Compliant: Designed for surveillance projects requiring NDAA-compliant equipment.
- 3-Year Manufacturer Warranty: Backed by a 3-year manufacturer warranty for added confidence and long-term product support.
Technical Specifications
| Model | HNRA20N-64 |
| IP Video Input | 64 Channels |
| Recording Resolutions | 32MP, 16MP, 12MP, 8MP, 6MP, 5MP, 4MP, 3MP, 1080p, 720p, D1, VGA, CIF |
| Video Compression | H.265+, H.265, H.264+, H.264, MJPEG |
| HDMI Outputs | 2 Independent HDMI Outputs |
| HDMI Resolution | Up To 4K / 3840 × 2160 |
| VGA Outputs | 2 VGA Outputs |
| Multi-Display Modes | HDMI1 / HDMI2 Independent Output; HDMI1 / VGA1 Simultaneous; HDMI2 / VGA2 Simultaneous |
| Synchronous Playback | Up To 16 Channels |
| Intelligent Motion Detection | Camera-Driven: 16 Channels / NVR-Driven: 8 Channels |
| Video Content Analytics | Camera-Driven: 16 Channels / NVR-Driven: 4 Channels |
| Face Capture & Recognition | 2 Channels |
| Face Picture Comparison | Up To 16 Channels From Compatible Cameras |
| Face Database | Up To 10 Face Libraries / 20,000 Pictures Total |
| License Plate Recognition | Up To 8 Channels With Compatible LPR Cameras |
| LPR Database | Up To 20,000 Plate Numbers |
| Smart Search | Up To 16 Channels With Compatible Cameras |
| SATA Ports | 8 Internal SATA Ports |
| Maximum HDD Capacity | Up To 16TB Per HDD / 128TB Total |
| Network Interface | 1 × RJ45 10/100/1000 Mbps Gigabit Ethernet |
| Built-In PoE Ports | None – External PoE Switch Required |
| USB Interfaces | Front: 1 × USB 2.0 / Rear: 2 × USB 3.0 |
| Serial Ports | 1 × RS-232 / 1 × RS-485 |
| Alarm Inputs | 16 Channels |
| Alarm Outputs | 6 Channels |
| Audio Input | 1-Channel RCA |
| Audio Output | 2-Channel RCA |
| Bandwidth – AI On | Incoming: 220 Mbps / Outgoing: 220 Mbps |
| Bandwidth – AI Off | Incoming: 400 Mbps / Outgoing: 400 Mbps |
| Protocols | HTTP, HTTPS, TCP/IP, IPv4, IPv6, UPnP, SNMP, RTSP, UDP, SMTP, NTP, DHCP, DNS, DDNS |
| Interoperability | ONVIF / RTSP |
| Mobile App | NeoViewer – iPhone & Android |
| Power Input | 100–240 VAC, 47–63 Hz |
| NVR Power Consumption | <13W Without HDD |
| Operating Temperature | -10°C to 55°C |
| Operating Humidity | 10% to 93% RH |
| Dimensions | 442.0 × 414.1 × 68.0 mm (17.4 × 16.3 × 2.7 in.) |
| Weight | 4.7 kg / 10.4 lb Without HDD |
| Warranty | 3-Year Manufacturer Warranty |
| Compliance | FCC Certified / NDAA Compliant |
Compatibility & Installation Note
This recorder does not include built-in PoE camera ports. A compatible external PoE switch or network infrastructure is required to provide power and network connectivity to PoE cameras.
Available intelligent analytics, face recognition, license plate recognition, smart search, recording resolution, and decoding performance depend on connected cameras, firmware versions, system configuration, and whether recorder-side AI functions are enabled.
For remote mobile access, use the NeoViewer Mobile App with compatible Premium NDAA equipment.
Important product information: Specifications are subject to change without notice. Features, storage support, audio functions, image performance, PoE behavior, compatibility and overall system performance may vary depending on firmware, recorder model, installation environment, network setup and system configuration. NVRs do not include hard drives unless explicitly stated.
