1080P HD Mini 2.4MP 4 in 1 HD AHD/CVI/TVI/CVBS Analog weatherproof Small Bullet Camera
***NO IR(NO Infrared)****
Features:
- 1/3" IMX323 HD CMOS
- Resolution 2Megapixel
- 2.8mm board lens, view angle of 90 degree
- DC 12V Power input (Power Adapter Not Included)
- BNC Video output
Specification:
| Model | |
| Image Sensor | 1/3" IMX323 CMOS |
| DSP | IMX323 |
| Horizontal Resolution | 2.4 Mega Pixel 1080P AHD CVI TVI CVBS 4 -In-1 |
| Effective Pixel | PAL : 1920X1080@25fps |
| NTSC : 1920X1080@30fps |
| Min. Illumination | 0.01 Lux (F1.2) |
| Signal System | NTSC/PAL |
| Electronic Shutter | PAL:1/50~1/100000s;NTSC:1/60~1/100000s |
| Max Transmission Distance | Common 75-3 lines can be up to 500m |
| Lens size | 2.8mm board lens |
| S/N Ratio | More than 46dB |
| Gamma | 0.45/1.0 |
| Exposure | Auto |
|
|
| Sync. System | Internal |
| Audio Output | Optional |
| Video Output | 1 Vp-p / 75 Ohms |
| Working Conditions | -20~60Degree |
| Power Supply | DC12V/75MA |
| Size | 20X75mm |
Package:
- 1x 2.4MP 4 in 1 Mini Camera
- 1X small Bracket
